Huawei XPON ONU (Mini Body)

The Huawei XPON ONU (Mini Body) is the most compact ONU in the Huawei XPON lineup, designed for ultra-space-efficient FTTH deployments. Despite its miniature size, it delivers full dual-mode GPON/EPON performance with a 1GE Gigabit Ethernet port.

Key Features:

• Ultra-compact mini body — smallest form factor in the range
• Dual-mode XPON — seamless GPON/EPON auto-adaptation
• 1 x Gigabit Ethernet (10/100/1000Base-T) RJ45 port
• SC/APC optical connector with Class B+ module
• Upstream 1310nm / Downstream 1490nm
• 20 km maximum PON transmission distance
• Power consumption under 2.5W — runs cool in enclosed spaces
• Integrated firewall and abnormal traffic protection
• LED indicators: POWER, PON, LOS, LAN

The mini body is the top choice for ISPs who prioritize aesthetics and minimal footprint at customer premises. Its tiny dimensions (78 x 78 x 21 mm) make it easy to mount behind routers, inside TJ boxes, or on walls without taking up visible space.
